The kitchen waste truck is independently developed and produced by Shenzhen Dongfeng Automobile Co., Ltd. It is designed for the collection and transportation of kitchen waste from the food service industry (hotels, restaurants, institutions, school canteens, etc.). With nearly 20 years of experience, the product series is comprehensive (covering 3T, 5T, and 8T models), offering reliable quality, excellent performance, and leading domestic standards in core metrics such as loading capacity, operational efficiency, and sealing technology. The EQ5121TCAS6 is a new-generation product carefully developed by Shenzhen Dongfeng, based on the actual needs of users. This truck features a modern, elegant design, built on the Dongfeng Motor Co. second-class chassis with added compartments, push blades, flipping mechanism, hydraulic systems, and electrical systems. It is powered by Dongfeng Cummins engines, meeting the National VI emissions standard.
This product is versatile, with low environmental requirements, making it suitable for urban streets, residential areas, the catering industry, hotels, canteens, and other large areas. It is mainly used for the collection and transport of domestic waste.
Waste is fed into the vehicle through the side flipping mechanism, with an initial separation of oil and water from catering waste. It integrates waste collection, compression, transportation, and unloading functions.
The side flipping mechanism can be compatible with 120L and 240L standard plastic waste bins, making it suitable for various catering waste collection and transportation needs.
Item | Parameters |
Model | EQ5121TCAS6 |
Chassis Model | Dongfeng Tianjin DFH1120B4 |
Total Mass (kg) | 12490 |
Approved Payload (T) | 8 |
Wheelbase (mm) | 3950 |
Dimensions (LxWxH) (mm) | 7660X2400X2975 |
Compartment Volume (m³) | 11.5 |
Sewage Tank Capacity (L) | 595 |
Flip Frame Cycle Time (s) | ≤15 |
Clean Water Tank Capacity (L) | 145 |
Unloading Method | Push-Blade Unloading |
1. Elegant Appearance
The vehicle boasts a streamlined, elegant design, showcasing a modern aesthetic.
2. Advanced and Reliable Control System
· Incorporates a highly intelligent electro-hydraulic integrated control system. The main control chip uses a German Siemens module, ensuring stable and reliable performance.
· Operation is simple and user-friendly (with an optional remote controller). The control panel complements the vehicle's aesthetic appeal.
3. Industry-Leading Loading Capacity
The compartment volume is among the best in its class. With optimal compaction force, the loading capacity exceeds 9 tons.
4. High Efficiency in Loading Operations
The lifting frame features dual-speed control, offering a short cycle time. Manual/automatic control options are available, supporting 120L and 240L plastic bins, achieving industry-leading efficiency.
5. Exceptional Sealing to Prevent Secondary Pollution
· The rear door and compartment connection utilize custom-engineered reinforced sealing strips.
· Two hydraulic cylinders control opening and closing at the top, while the bottom features wedge-shaped locking with two hydraulic cylinders. The adjustable top locking design ensures structural strength, simple operation, and excellent sealing.
· Integration of electro-hydraulic control prevents leaks during operation or transit, effectively avoiding secondary pollution.
6. Efficient and Reliable Unloading (Optional Sealed Discharge)
· Push plate rails and hydraulic cylinders are aligned at the same height, minimizing resistance and ensuring smooth operation.
· Unloading time ≤ 100 seconds, leading the industry in efficiency.
7. Safety Features
· Rear door lifting circuit is designed with a balance valve to reduce impact and ensure smooth operation. Safety support rods on both sides of the rear compartment provide dual protection during maintenance.
· Linked control between the rear door locking and lifting cylinders prevents operational errors.
· Anti-drop mechanisms on the lifting frame enhance safety, preventing harm to operators and secondary pollution.
8. Integrated Sewage Tank
· Sewage from the compartment floor filters into the tank for preliminary oil-water separation.
· Features a front-end cleaning device for easy maintenance and a rear-end ball valve controlled by a pneumatic cylinder for convenient sewage discharge.
9. Freshwater Tank System
· A built-in freshwater tank (at the front of the compartment) is filled via a left-side bottom inlet and monitored by a water level gauge. It supports high-pressure cleaning and reduces labor intensity.
10. High-Pressure Cleaning System
· Employs an oil pump → motor → high-pressure water pump system, generating 10 MPa of water pressure for cleaning the compartment and ensuring hygiene during operations.
11. Optional Screw Discharge Mechanism
· An optional screw discharge system driven by a hydraulic motor rotates to expel waste through a gate without opening the rear door. This enhances operational efficiency and prevents secondary pollution.
12. Optional Weighing System
· A flip-frame weighing system can be installed, providing real-time bin weight data. Features include full-load alarms and GPS tracking capabilities.
13. User-Friendly Design
· Equipped with storage boxes, work lights, and ladders for customer convenience.
14. Optimized Pipeline Layout
· Hydraulic and electrical pipelines are neatly arranged, ensuring a clean and professional appearance.
15. Low Fuel Consumption
· Engine speed is automatically adjusted based on operational status. Idling speed ≤ 800 RPM; working speed (e.g., for compaction or cleaning) ≤ 1500 RPM. Low fuel consumption reduces operational costs.
16. Clean and Efficient Discharge
· Push plate rails are located on both sides inside the compartment, which is box-shaped for thorough unloading with no residual waste.
17. Durable Stainless Steel Components
· Key areas, such as the compartment arc panels, rear door, and push plate, are made from stainless steel, offering excellent resistance to corrosion and ensuring a long service life.
